Engineering Graphics is a compulsory subject for all branches of engineering as it is the graphical language of engineers. In this book the author draws upon his vast experience of teaching and presents a student friendly step -by step demonstrative approach similar to that of classroom teaching. Apart from VTU this book has been recommended as Text/Reference book by the following universities under the title Computer Aided Engineering Drawing: (i) Mechanical Diploma Course, Karnataka (ii) JNTU Hyderabad (iii) JNTU, Kakinada (iv) UP Technological University, Lucknow (v) Nagpur Technological University, Nagpur (vii) Gujarat Technological University Gujarat and vtarious VTU affiliated colleges.
